Brand:
GoosunItem NO.:
GC-144M(182) 570-590Order(MOQ):
10pcsPayment:
T/T,L/CPrice:
$0.16Price Range:
50000 - 100000/$0.14Price Range:
15000 - 50000/$0.15Product Origin:
ChinaColor:
Dark blueShipping Port:
Shanghai Ningbo QingdaoLead Time:
within 2 weeksProduct Detail
Product Specifications
Mechanical Specifications
Cell Type |
TOPCON |
No.of Cells |
144(6×24) |
Dimension |
2278x1133x30mm |
Weight |
31.8kg |
Glass |
3.2mm, high permeability, AR coatedthermally strengthened glass |
Frame |
Anodized Aluminium Alloy |
Junction Box |
IP68,3diodes |
Output Cables |
4mm², Length 300mm or customized |
Connector type |
MC4 compatible |
Application |
Solar Power System |
Per Pallet |
36pcs |
Per 40' HQ Container |
720pcs |
Module Type |
GC-144M-570 |
GC-144M-575 |
GC-144M-580 |
GC-144M-585 |
GC-144M-590 |
Testing Condition |
STC NOCT |
STC NOCT |
STC NOCT |
STC NOCT |
STC NOCT |
Maximum power(Pmax) |
570 426 |
575 430 |
580 433 |
585 437 |
590 441 |
Open circuit Voltage(Voc) |
51.91 48.74 |
52.06 48.88 |
52.21 49.02 |
52.36 49.16 |
52.51 49.30 |
Short circuit current(lsc/A) |
14.07 11.36 |
14.14 11.42 |
14.20 11.47 |
14.27 11.52 |
14.33 11.57 |
Voltage at maximum power (Vmpp) |
43.76 39.93 |
43.91 40.07 |
44.06 40.20 |
44.21 40.34 |
44.36 40.47 |
Current Maximum power(Impp) |
13.03 10.68 |
13.10 10.73 |
13.17 10.78 |
13.24 10.84 |
13.31 10.89 |
Module efficiency (%) |
22.10% |
22.30% |
22.50% |
22.60% |
22.83% |
Power Tolerance (w) |
0~+5 |
0~+5 |
0~+5 |
0~+5 |
0~+5 |
STC: Irrdiance 10oow/m2, Cell Temperature 25°℃, Air MassAM1.5.
NOCT: rradiance at 8oow/m2 ,Ambient Temperature 20°℃, Wind Speed 1m/s.
Pmax/W |
Voc/v |
lsc/A |
Vmp/v |
lmp/A |
Pmax gain |
604 |
51.30 | 14.84 | 43.11 | 14.00 | 5% |
633 | 51.30 | 15.55 | 43.11 | 14.67 | 10% |
661 | 51.40 | 16.26 | 43.21 | 15.34 | 15% |
690 | 51.40 | 16.96 | 43.21 | 16.01 | 20% |
719 | 51.40 | 17.67 | 43.21 | 16.67 | 25% |
NOCT Temperature |
45°℃士2°℃ |
Temprature Coefficient (Pmax) |
-0.290%/°C |
Temprature Coefficient (Voc) |
-0.230%/C |
Temprature Coefficient (lsc) |
0.050%/°C |
Maximum system voltage (IEC)
1500V DC (IEC)
Snow / wind
5400Pa / 2400Pa
operating Temperature
-40°℃~+85°C
Maximum series fuse rating
30A
1.Who are we?
We are based in Anhui, China,start from 2012,sell to . There are total about 101-200 people in our office.
2. How can we guarantee quallty?
Always a pre-production sample before mass production;Always final lnspection before shipment;
3.What can you buy from us?
Solar Panel, Solar Inverter, Solar System
4.Why should you buy from us not from other suppllers?
1.High productivity, Automatic production line, and Advanced facilities
2.Minimalist designs, individulisation in perfection
3.35-year warranty, factory sale directly
4.OEM ODM OBM service, quick lead time
5. What servlces can we provlde?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;
Accepted Payment currency:uSD,EUR,AUD,HKD,CNY;
Accepted Payment Type:T/T,L/C,D/P D/A,Credit Card,Cash;
Language Spoken:English,Chinese
